• Monopulse Transmitter: 1-200Mhz bandwidth, 24kW peak power, and 1.6kV into 50 Ohm. Rise time is less than 2ns. Repetition rate is 512Hz. Weight is 200g, typical transmit consumption: 200 mA

• Digitizer:
  NI-5133: 8-bit, up to 50Mhz, up to 100MS/s, ~1.15 W power consumption, ~250g.
  Pico 4224: 12-bit, up to 20MHz, up to 80MS/s, ~2.5 W power consumption, ~ 450g.
  Pico 4227: 12-bit, up to 100MHz, up to 250MS/s, ~2.5 W power consumption, ~ 450g.


• EPU (Embedded Processing Unit): Intel Atom 1.6GHz based, SSD-equipped, Operating -10oC to + 50oC, storage -20oC to 60oC, 12-24 V power supply, typical consumption including EPU, digitizing board, GPS: ~ 900 mA at 12V

• GPS unit: 95g.

• Contact us if you want to integrate other digitizer models or require customization.

Contact Laurent Mingo at Blue System Integration for details. 604.726.1817.
